ACTION SERIES 200 – Black Rubber Suction Hose

ACTION SERIES 200

Black Rubber Suction Hose with wire helix

Cover is abrasion & weather resistant

Cover Color:

Black w/Yellow stripe

Oil Resistance:

Moderate

Tube:

Smooth EPDM

Reinforcement:

Two-ply or four-ply synthetic fabric with a double wire helix

Temperature Range:

−25°F to +185°F (−32°C to +85°C)

Application:

For suction, discharge or gravity flow of water in construction, mining, oil exploration, agriculture and equipment rental

I.D. (Inches)	O.D. (Inches)	Part Number	Reinforcement Spirals	PSI	Weight (lb/ft)
1 1/2	1.96	20015	2	150	0.80
2	2.49	20020	2	150	1.11
2 1/2	2.99	20025	2	150	1.75
3	3.50	20030	2	150	2.24
4	4.53	20040	2	150	2.79
6	6.54	20060	2	150	5.75
8	8.79	20080	4	100	6.59
10	10.91	200100	4	75	10.25
